Brand — the iterion-bot mascot, everywhere iterion shows a face

The mascot on the official iterion-bot GitHub account is iterion's identity: the product logo, the favicons, the desktop icon, and the avatar of every account a bot posts through. This runbook covers both halves — the asset pipeline, and how each forge identity gets the face (automatically where the forge has an API, by hand where it has none).

The assets — one source, generated copies

Where	What	Consumer
assets/brand/iterion-bot.png	master, plain — the mascot on a transparent background, 460×460, pixel-equal to the iterion-bot account's avatar	every account avatar
assets/brand/iterion-bot-circle.png	master, badge — dark disc + ring, 1254×1254	every product surface
pkg/brand/*.png	plain 460, lossless (the master's own pixels; < 200 KiB, GitLab's limit) + circle 512, go:embed	forge.AvatarSetter uploads; GET /brand/iterion-bot.png + /brand/iterion-bot-circle.png (public)
studio/src/assets/iterion-mark.png	circle 256	the studio's BrandMark (sidebar, landing, shells)
studio/public/{android,apple,ms,favicon}-*.png, favicon.ico (16/32/48)	the favicon pack; the Apple icons on a flat navy (iOS renders alpha as black), the rest transparent	index.html, manifest.json, browserconfig.xml, service-worker.js
docs/public/iterion-logo.png, docs/images/iterion-logo.png, docs/public/favicon.ico	circle 512	VitePress nav + hero, the README banner
docs/public/og.png	1200×630 card	OpenGraph / Twitter preview
build/appicon.png, cmd/iterion-desktop/appicon.png	circle 1024	Wails derives .ico/.icns; desktop-release.yml, the .deb/AppImage stage, the Helm chart icon:

Every row but the masters and og.png is generated:

task brand:gen     # scripts/brand/generate.sh — magick + pngquant + oxipng from devbox
task brand:check   # regenerates into a temp dir and cmp's each copy (part of `task check`)
task brand:og      # docs/scripts/og-card.html → docs/public/og.png (needs `task test:e2e:ui:install`)

brand:check runs in task check, not in CI (it needs the devbox toolchain, like pi-ext:check); a toolchain bump (devbox update) can change the bytes, and the answer is the same as for a master change: regenerate and commit. Change the mascot = replace a master, run brand:gen then brand:og (the OG card embeds the regenerated docs logo and has no guard of its own), commit everything they touched. Never edit a generated copy: brand:check fails on it, and on a committed copy the script no longer produces. The output is deterministic (stripped metadata, fixed quantiser), which is what makes the check a byte comparison.

Forge identities — who gets the face, and how

The identity a bot posts with is the connection's account (forge-permissions.md). Whether iterion can put the avatar on it depends on the forge:

Connection	Avatar	How
GitLab PAT whose account GitLab flags bot: true — a group/project access token's bot user, a service account	automatic at connect time (PUT /user/avatar, GitLab ≥ 17.0)	the connect records account_kind: bot and avatar_applied_at; a refusal lands on avatar_error, never fails the connect
GitLab / Forgejo PAT of a dedicated account the forge does not flag (a hand-made iterion-bot user; every Forgejo account — no bot flag there)	on demand, with the operator's word	studio → Integrations → the connection card → Apply iterion-bot avatar (confirms, then force), or iterion remote forge connections avatar <conn-id> --force
OAuth connection (any forge)	never	it authenticates as the person who authorized it; iterion does not rebrand personal accounts, no override
GitHub App (iterion-forge-*, iterion-watch-*)	manual	GitHub has no logo API and the manifest cannot carry one: the studio shows the hand-off after creation (download link + the App's Display information page) and keeps a Logo ↗ link on the App row
GitHub PAT / user account	manual	no avatar API either; iterion-bot already wears it

Apply state on a connection: account_kind, avatar_applied_at, avatar_error (GET /api/teams/{id}/forge/connections). The action: POST /api/teams/{id}/forge/connections/{conn_id}/avatar {variant?: plain|circle, force?} — 422 with logo_url + logo_circle_url on GitHub (plus manage_url when the App is one iterion created); 422 on a revoked connection, or on a token the forge rejects at apply time (the connection is marked revoked with the reason — reconnect first); 409 needs_force on an account the forge does not flag as a bot, or would not describe at all (a token without the scope): iterion cannot vouch, the operator can; 502 when the forge did not answer the identity read (unreachable, timeout, 5xx, no user endpoint at that base URL — no upload was attempted) or when it refused the upload — the message says which. Audit event on both the automatic and the explicit path: forge.connection.avatar_applied (automatic: true at connect time).

Escape hatch: ITERION_FORGE_BRAND_AVATAR=off on the server disables the connect-time upload deployment-wide; the explicit action stays.

GitHub App — the manual upload, step by step

1. Download /brand/iterion-bot.png (plain, matches the iterion-bot account) or the badge /brand/iterion-bot-circle.png from any iterion server — or take assets/brand/iterion-bot.png from the repo.
2. Open the App's settings: the Logo ↗ link on the App row (Integrations → Manual setup → Forge OAuth apps), or GitHub → the org → Settings → Developer settings → GitHub Apps → the App → General.
3. Under Display information, Upload a logo…, then Set new avatar in the crop dialog. The logo is live at that click — the form's Save changes button belongs to the basic information above it, not to the logo. Comments and commits signed by <slug>[bot] carry the avatar from then on.

An OAuth App (the iterion SSO app) takes the same file through Application logo → Upload new logo → Set new application logo.

Done on the SocialGouv org on 2026-09-06 (the four iterion-forge-* / iterion-watch-* Apps and the iterion / iterion preprod OAuth Apps). An App the manifest flow creates afterwards starts without a logo: repeat the steps.

GitLab group bot accounts already connected (the PIC)

A connection created before this feature carries no account_kind: the first apply asks the forge who the token is (WhoAmI), records what it learns, and judges the account — a group-token bot user needs no --force. Apply once per connection; the upload goes through the sealed token:

iterion remote forge connections avatar <conn-id>          # bot user of the GAT
iterion remote forge connections avatar <conn-id> --force  # an unflagged dedicated account

The GAT must be alive (the upload authenticates as its bot user); a revoked/expired token answers forge: credential rejected. Verify on GitLab: glab api users/<bot-user-id> --jq .avatar_url.

Commits

Nothing to do: the runner already signs commits with the account's canonical noreply address (pkg/runner/git_identity.go), so a commit shows the App's logo / the bot user's avatar once that is set.
